Increase number of undo levels (V5) - Default number of undo levels are 10. If you should have the need to resize your tree afterwards, hold Ctrl while scrolling the mouse wheel instead. Select General > Display > Tree Manipulation (Disable this box) (Unless of course this had been disabled already.)Ĭlick Tools > Options.
When you click OK the new geometrical set will be moved into the one selected as Father with all pre-selected geometrical elements moved into the new set.Īvoid zoom on tree (V5) - If you try to click the + sign in your spec tree but miss and click a branch instead your model will get a darker shade and all your space mouse movements will affect the spec tree instead of the model. If you leave this field blank your new set will be named Geometrical Set.n, where n is the next available number in line. Type a name of the new set in the name field. If you have defined a geometrical set as your 'In work object' this will be set as 'Father' by default. In the 'Father' field, select the set you want the new set to be included into. All your previously selected elements are listed in the 'Features' field. This method however may save you some work.įirst select all the elements you want to move into the new Geometrical Set. Organizing in Geometrical Sets (V5) - Very often when you make a new geometrical set you move the desired elements into them afterwards.
Here's a few V5 tips and tricks courtesy to Christian Bunes:
